Lenz Silver 10321-01 21 Pin Decoder

£29.67

Lenz Silver 21 Pin Decoder

The DIGITAL plus SILVER 21 locomotive decoder has a built in NMRA 21 pin
plug and is suitable for all DC locomotives with continuous current draw of 1.0
Amp. or less. For OO/HO models with 21MTC decoder plug

Size: L 20.5 mm x W 15.5 mm x H3.92 mm



5 in stock

SKU: 10321-01 Category: Tag:

Description

Lenz Silver 10321-01 21 Pin Decoder

Lenz Silver 21 Pin Decoder

The SILVER 21 + is like the Silver +, but equipped with a 21 pin interface plug located on the circuit board and even more space saving due to its 2.5 mm shorter design.

The DIGITAL plus SILVER 21 locomotive decoder has a built in NMRA 21 pin
plug and is suitable for all DC locomotives with continuous current draw of 1.0
Amp. or less. For OO/HO models with 21MTC decoder plug

Try Our Decoder Selector Here

Some information on Lenz Decoders well worth noting if you are considering which decoder to buy, over the years we have only experienced 1 genuine failure on a Lenz decoder and 1 failure on a controller despite having sold many hundreds. One of the main reasons for this is that accross the range of lenz decoders they are protected by good quality thermal overload circuits. A short circuit is detected but also when a long overload causing similar thermal damage occurs the drive circuit is shut down and fully protected. This means that instead of simply blowing when under conditions of short or overload like many US based decoders with inferior circuitry, they will simply cut out and allow you to reset either by thermal reset or overall reset. Essentially it is very difficult to lose a Lenz decoder through short circuit so you get a second chance instead of a puff of smoke. They are more expensive but they are worth it

The characteristics of the decoder are:

Super smooth and silent high frequency back-emf motor control.
Supports Automatic Braking Control (ABC)
Adjustable precision stopping control.
Shunting speed on F3
Selectable for operation with 14/27, or 28/128 speed steps.
Operation on conventional DC layouts is possible or can be disabled.
Motor output = 1A continuous, 1.8A max, > 5 A stall.
Motor and function outputs protected.
Four function outputs rated at 100mA each with advanced function mapping.
Directional or independent lighting with dimming and special effects.
Support for Multiple traction and long addresses (Loco addresses up to 9,999)
Support for programming on the mainline (Programming on Main POM).
Support for all form of programming as described in NMRA RP-9.2.3
RailCom
Size: L 20.5 mm x W 15.5 mm x H3.92 mm

Additional information

Weight 50 g
